HR3051-GP/AP Gauge Pressure Transmitter

The HR3051-GP/AP Gauge/Absolute Transmitter is used to measure the liquid level density and pressure of a liquid gas or vapor and then convert it to a 4-20 mADC HART current signal output. The HR3051-GP/AP can also communicate with the RST375 handheld terminal or the RSM100 Modem for parameter setting process monitoring and more.

Range zero externally continuously adjustable

Solid component plug-in printed circuit board

No mechanical moving parts less maintenance work

Full range of unified structure strong interchangeability of parts

Positive migration up to 500% negative migration up to 600%

One-way overload protection features are small lightweight and robust

Product related

Download: 点击下载
Brand : 恒瑞HighReach
Model : HR3051-GP/AP
Mailbox : highreach@hr-tool.cn
Phone : 0917-3208995

Technical Parameters

Ambient temperature effect

Range code	-20℃～65℃Total effect value
B/L	±(0.30×TD+0.20)%×Span
other	±(0.20×TD+0.10)%×Span
Range code	-40℃～-20℃和65℃～85℃Total effect value
B/L	±(0.30×TD+0.20)%×Span
other	±(0.20×TD+0.10)%×Span

Over range effect：±0.075%×Span

Long-term stability

Range code	impact
B/L	±0.2%×Span/1year
other	±0.1%×Span/1year

Power impact
±0.001% /10V (12～42V DC) negligible

2Functional specification
Range and limit (HR3051-GP gauge)

Range/limit		kPa	bar
B	Range	0.6～6	6～60mbar
B	limit	-6～6	-60～60mbar
C	Range	2～40	0.02～0.4
C	limit	-40～40	-0.4～0.4
D	Range	2.5～250	0.025～2.5
D	limit	-100～250	-1～2.5
F	Range	30～3000	0.3～30
F	limit	-100～3000	-1～30
G	Range	0.1～10MPa	1～100
G	limit	-0.1～10MPa	-1～100
H	Range	0.21～21 MPa	2.1～210
H	limit	-0.1～21 MPa	-1～210
I	Range	0.4～40 MPa	4～400
I	limit	-0.1～40 MPa	-1～400
J	Range	0.6～60 MPa	6～600
J	limit	-0.1～60 MPa	-1～600
