Technical Parameters

Features

• High stability sensor for liquid level measuring nice stability on long-term service
• High accuracy up to 0.05% F.S;
• Temperature measurement resolution 0.05 C
• Conductivity measurement better than 1.5% F•S;
• F.S  temperature compensation and digital calibration;
• Absolute pressure level measurement no air duct which greatly improved reliability
•  High overload capacity;
• Wide power supply 5 ~ 30VDC;
• RS485 standard MODBUS-RTU protocol;
• Internal recyclable record over 30000
• Low power consumption sleep current operating current <5μA
• The product also has reverse power protection and surge protection
• All stainless steel housing sealing structure IP68 protection


Conductivity sensor measurement performance indicators:
Adopt international top four-electrode technology RS485 digital interface support MODBUS protocol environmentally friendly design. Compared with the traditional two-electrode conductivity sensor it has higher accuracy wider measurement range and excellent stability. The four-electrode conductivity sensor also has a unique advantage in quantity: one is to completely solve the polarization problem in high conductivity test; the other is to solve the problem of inaccurate reading caused by electrode contamination.

• 1uS/cm~200 mS/cm accuracy 1.5% F.S
• RS485 output， support Modbus，communication protocol can open
• 0~50℃，protection level IP68，max. pressure 6bar
• Can not be polarized can be used online continuous
• Wide range and application
• Very resistant to pollution and strong anti-interference ability
• Stable in measurement and the accuracy is higher
• Strong structure and long service life

Related parameters
